Advantages |
Electrical System |
 |
24 volt electrical system incorporating – Transistor "MOSFET" CURTIS, microprocessor controlled with onboard service diagnostic capability. |
 |
The controller provides many benefits such as maximum energy efficiency, reduced maintenance and infinite speed control capacity. |
 |
Through a flash code signaled by an LED - 17 detectable faults can be recognized. |
 |
Using an optional handset, faults can be displayed digitally. |
 |
Controller settings are programmable, which will be done by our service personal only. |
 |
An impact button provides emergency stop, which makes the power cut off to all components in case of any emergency and which is easily accessible to the operator. |
 |
The display console is placed directly in the operator field view and indicates the battery charge status. |
 |
Contactors of CURTIS/ALBRIGHT – a.Forward/Reverse, b. Main Contactor,c.Pump Contactor, with which we can operate at high current range. |
 |
The control and power circuits are operated through fuses for protection. |
 |
All wiring & power controls are number coded. |
 |
The safety-reversing device on the tiller head prevents the operator being squeezed between the tiller arm and obstacles behind. |
|
Options |
 |
Wide version |
 |
Long fork |
 |
Sloping fork for paper roll |
|
Drive Unit/Brake |
 |
A heavy-duty 24-volt series wounded integrated with fully closed oil lubricated heavy-duty gearbox with spur input gear for low emission. |
 |
The drive unit is manufactured by CFR Italy. |
 |
This drive unit is equipped with an Electromagnetic Coil Brake. |
|
Hydraulic System |
 |
Heavy-duty 24 V, 2 KW pump motor and gear pump is used for optimum performance. |
 |
The lifting and lowering function are controlled by DC Solenoid Valve, overload pressure relief valve, and protects the system from pressure overload. |
 |
The lift cylinder rods are hard chrome plated with polyurethane seals. |
 |
The lowering brake valve ensures lowering safety, steel pipes connects hydraulic components in the circuit. |
 |
Hydraulic oil tank with enough oil, as much as the system requires. |
 |
The drain plug provided at the bottom of the tank helps in draining the oil without dismantling any other part of the system. |
|
Operator Controls |
 |
The control handle is designed for an optimum turning radius with low steer effort. |
 |
The key switch and horn button are in the handgrips. |
 |
An ergonomic forward/reverse thumb wheel allows precise maneuvering. |
 |
An oil damped gas spring returns the tiller arm to the safe vertical position automatically. |
